Salescaster® Outdoor LED Time and Temperature Signs alternate between the current time and outdoor temperature, giving passing customers useful information and helping them recognize your location. Choose Digit heights from 8″ to 36″ inches, Red, Yellow or Green LEDs and front or rear service access.
For bank sign conversions and other retrofit projects, Salescaster® can help match the display and custom cabinet dimensions to your existing sign opening. Automatic dimming adjusts LED brightness to ambient light conditions.
Salescaster TT800 Red LED 8-inch Character Alternating Time & Temperature Sign
Replace an older incandescent time and temperature display or plan a new outdoor installation. Standard cabinet depths are 3.75 inches for TT800 through TT1900 and 4.25 inches for TT2400 through TT3600. Custom cabinet height and length are available for retrofit projects.
LED Time and Temperature Sign Models and Specifications
| TT Model | Digit Size | Cabinet Length |
Cabinet Height |
Cabinet Depth | Weight | Max Viewing Distance |
Power 120VAC Amp |
| TT 800 | 8.0″ | 25.25″ | 12.00″ | 3.75″ | 15 lbs. | 360 ft. | 1 |
| TT1000 | 10.0″ | 32.50″ | 14.25″ | 3.75″ | 20 lbs. | 450 ft. | 2 |
| TT1200 | 12.0″ | 39.00″ | 15.75″ | 3.75″ | 26 lbs. | 540 ft. | 2 |
| TT1500 | 15.0″ | 46.50″ | 19.25″ | 3.75″ | 32 lbs. | 675 ft. | 2 |
| TT1900 | 19.0″ | 57.00″ | 23.25″ | 3.75″ | 40 lbs | 855 ft. | 2 |
| TT2400 | 24.0″ | 72.00″ | 30.00″ | 4.25″ | 82 lbs | 1080 ft. | 2 |
| TT3200 | 32.0″ | 110.00″ | 38.00″ | 4.25″ | 145lbs | 1440 ft. | 3 |
| TT3600 | 36.0″ | 115.00″ | 42.00″ | 4.25″ | 160lbs | 1620 ft. | 3 |
Cabinet height and length can be customized for retrofitting existing signs. Contact Salescaster® for help choosing the digit size for your installation.
Request a Quote Call 800-346-4474
Outdoor LED Display Features
Energy Efficiency
- LED Technology uses 95 percent less energy than other light sources.
- Energy Efficient Smart LED technology is affordable, reliable and uses minimal energy.
Display Sizes, Colors and Visibility
- LED Color: Red, Yellow or Green
- Many modular sizes from 8.0” – 36.0” Digit
- Discrete LEDs provide wider viewing angle and daytime visibility.
Cabinet Construction and Service Access
- Front or Rear Serviceable
- Rugged outdoor-grade aluminum cabinetry: 3.75″ or 4.25″ depth, depending on model.
- Non-glare Lexan face for vandal resistance.
- High-Impact Acrylic Lens Front for Protection.
Timekeeping and Temperature Controls
- GPS is Standard.
- Alternating Time and Temperature Displays.
- Temperature Display is Configurable: Fahrenheit, Celsius or Alternating F/C.
- Time Display is Configurable: 12 hour or 24 hour Format.
- Automatically Adjusts for Daylight Savings Time and Leap Years.
- Digital Temperature sensing for increased accuracy and reliability.
- Battery Backup: Time Retention During Power Outages up to 10 Years.
Outdoor Operating Conditions
- Operational Temperature Range: -30°F to +120°F.
- Designed for Extreme Temperature and Humidity Applications.
Warranty
- Five-year warranty from the ship date.
Choosing a Time and Temperature Sign
Tell us how far viewers will be from the sign, the available sign opening, your preferred LED color, and whether service access is from the front or rear. The model table compares digit height, cabinet dimensions, weight and electrical requirements. Salescaster can help you select a display for your site.
Custom Cabinets and Retrofit Projects
For an existing sign, provide the opening width, height and available depth, along with photos of the cabinet and mounting location. Ask us to review mounting, power connections and temperature-sensor placement for your project. GPS is standard. The warranty is five years from the ship date.
Frequently Asked Questions
Select a question to view the answer.
Request a Time and Temperature Sign Quote
Send your installation location, preferred digit height and LED color, cabinet measurements, and any retrofit photos. Contact Salescaster to discuss the configuration and installation requirements.
